wire saw China What do you know about the operation of stone cutting machine?

Time：2018-07-09 Hits：2897

What do you know about the operation of stone cutting machine?

manual adjustment

(1)The solenoid handle of the automatic air switch shall not be put into the "closed" position until it is confirmed that all electrical appliances and their connection wires are correct.

(2) the upper and lower stroke switch position, the user should be determined according to the height of stone material, the stroke switch position, make the lift touch block pressing travel switch when lifting, lifting motion control;

(3) left and right travel switch position, the user shall be determined according to the length of stone left and right position of stroke switches, make left and right touch block in the car to the left or the right movement when pressing left and right journey begins, implement reciprocating movement; The user manually adjusts the time relay pointer to the required position according to the hardness of the cut stone plate. Its reference amount: 1 second cutting amount: 3.8mm; 2 seconds cutting amount: 7.6mm.
(2) automatic adjustment
First, after adjusting by manual adjustment steps, start the host machine, and press the automatic button when the host machine has finished the y-surround operation, and the cart can work back and forth automatically
(3) matters needing attention
If at the time of stone sawing, car has been around from travel switch, all of a sudden power failure, the air switch handle plate must be to "points" position, when to call first according to the "rising" button to make the knife dish rise up a knife, and then press "left" or "right" button, the machine garage to right side or left side position, press automatic button again continue to cut stone.
